Mechanical Calibration
As you can see, the breadth of our capabilities allows us to respond to the diverse mechanical calibration which covers sub-parameters Dimension, Pressure, Mass & Volume, Force, Torque, etc. TCLPL also offers vibration, density, acoustics, acceleration and speed calibration under their mechanical calibration services.
Our calibration ensures that their equipment and instruments will perform at their optimal level, every time.
What We Offer
Offerings | Technical Specification | Description |
Bevel Protractor Calibration | 0 to 360° | Angle measurement Scale and Acute angle flatness and Parallelism |
Centre Distance Gauge Calibration | 0 to 2000mm | Linear calibration |
Centrifuge Calibration | 10 – 90000 RPM | Speed Calibration |
Coating Thickness Gauge Calibration | 0 to 3000 Microns | Linear error and foils thickness measurement |
Combination Set Calibration | 0 to 180° | Angular scale, Flatness of scales |
Micrometer Calibration | 0 to 300 mm | Linear measurement |
Dial Bore Gauge / Bore gauge Calibration | Calibration up to 2mm | Diameter measurement |
Dial Depth Caliper Calibration | 0 TO 300 mm | Linear measurement |
Dial Thickness Gauge Calibration | Calibration up to 50 mm | Turns, sensitivity, hysteresis and repeatability |
Digimatic Height Gauge Calibration | 0 to 600mm | Linear measurement |
Engineers Parallel /Rectangular Block Calibration | 0 to 300 mm | Thickness, width and parallelism calibration |
Feeler Gauge Set Calibration | 0.01mm to 2mm | Thickness measurement |
Glass Scale Calibration | 0 to 300 mm | Linear Measurement |
Micrometer Calibration | Up to 100 mm | Linear measurement |
Hegman gauge Calibration | 0-100micron | Thickness measurement |
Hydrometer Calibration | 0.6-1.6 g/ml | Linear scale by cuckoos method |
Inside Dial Caliper Calibration | 5mm to 100mm | Inside Dial Caliper, Outside Dial Caliper, Pistol Caliper |
Lever Dial Indicator Calibration | 0 to 2mm/0.001mm | Lever Dial Indicator Calibration |
Micrometer Head Calibration | Up to 50 mm | Basic micrometer calibration |
Measuring Tape Calibration | 0 to 30 Mtr | Calibration as per standard |
Pin Gauge Set Calibration | Calibration for all Types | Diameter Minimum and Maximum |
Plain Ring Gauge Calibration | 0 to 500 mm | Plain Ring Gauge |
Plunger Dial Indicator Calibration | 0 to 100mm/ 0.02mm | Turns, sensitivity, hysteresis and repeatability |
Radius Gauge Set Calibration | Up to 40mm | Per radius or per pitch |
Scale Calibration | 0 to 1000 mm | linear measurement |
Slip Gauge Set Calibration | up to 100 mm (Grade 0, I, II) | Thickness measurement |
Snap Gauge Calibration | 1mm to 400mm | Size measurement for Min and Max reading (Snap Gauge/ Gap Gauge (Go and No-go)) |
Sound Level Meter Calibration | 95db and 114 dB | Acoustic sound at fixed points |
Spirit Level /Electronic Blue level Calibration | 0-300mm / 0.01 mm/Mtr | LHS and RHS calibration |
Straight Edge Calibration | 0 to 1200mm | Straightness Measurement |
Surface Plate Calibration | 400 x 400 mm | Flatness measurement surface |
Surface Roughness Master Calibration | All types of roughness calibration | Roughness calibration |
Tachometer Calibration | 10 to 3000RPM – Contact type | Speed Calibration |
Scale Calibration | 0-1000 mm | |
Test Sieves Calibration up | up to 500mm | |
Elongation /Flakiness Gauge calibration | verious | |
Thread Plug Gauge Calibration | Calibration up to 200mm and above | Major Diameter, Effective Diameter- Minimum and Maximum. |
Thread Ring Gauge Calibration | Calibration up to 150 mm (NPT Go or No-go) | Effective Diameter- Minimum and Maximum. |
Torque Wrench Calibration | 0.2 to 2000 Nm | Torque Wrench Calibration at 20% 60% 100% of full range as per standard |
Ultrasonic Thickness Gauge Calibration | up to 100mm | Linear measurement |
Micrometer Calibration | up to 600mm | Linear measurement |
V Block Calibration | 100 mm, 150mm and 300mm | Flatness Parallelism Perpendicular |
Vernier Caliper Calibration | 0 to 1000 mm | internal/external jaw and flatness and parallelism error |
Vernier Height Gauge Calibration | 0 to 600 mm | Linear measurement |
Cube mould | Various | Linear measurement |
Weld Fillet Gauge Calibration | Up to 50 mm | Radius Measurement |
Width Gauge Calibration | 0 to 300mm | Actual size go/no-go |
Wire Gauge Calibration | 0.025mm to 10mm | Gap measurement |
Impact Testing Machine Calibration | All ranges Calibration | Impact Testing machine Charpy |
Push Pull Meter Calibration | 5N to 500N | Calibration in push and pull mode |
Tensile Testing Machine Calibration | up to (50 kN) | Spring Testing Machine Calibration |
Univeral Testing Machine Calibration | up to (1000 kN) | Compression Mode (Universal / Tensile / Compression Testing Machine) |
Brinell Hardness Tester Calibration | Indirect and Test Force Verification | Indirect and Test Force Verification |
Load Verification of Hardness tester Calibration | 3 kg to 3000 kg | Load verification with Indirect calibration |
Load or Cube Testing Machine Calibration | up to (2000 kN) | Compression Mode |
Optical Brinell Hardness Tester Calibration | Indirect and Test Force Verification | Indirect and Test Force Verification |
Rockwell Hardness Tester Calibration | Indirect Verification | Indirect Verification |
Rubber Hardness Tester Calibration | 0-100 shore A&D | Shore A, D, type, Calibration by Spring force / Indentation depth calibration method |
Vicker Hardness Tester Calibration | Indirect and Test (1kg to 30kg) | Indirect and Test Force Verification |
Loose Weight Calibration | 0 to 30 Kg | Loose Weight Calibration |
Spring Balance | Up to 50kg | Calibration checked for linear error, repeatability, hysteresis and eccentricity |
Weighing Scale / Weighing Balance Calibration | Calibration up to 300kg | Calibration checked for linear error, repeatability, hysteresis and eccentricity |
Weight Set Calibration | 1mg to 200gm (Class-F2, M1, M2) | Analytical Weight Box calibration |
Dispenser Calibration | 10ml to 100 ml | Volume Calibration |
Measuring Cylinder Jar Calibration | 1ml to 2000ml | Volume Calibration |
Micropipette Calibration | 10µL to 10 ml | Volume Calibration |
Pipette, Burette and Measuring Cylinder Calibration | 0.1ml to 100ml | Volume Calibration |
Volumetric Flask Calibration | 1ml to 2000ml | Volume Calibration |
